优点:
机械是出厂硬纸芯(xin)、软纸芯(xin)、等小圈筒纸(小礼品(pin🐓)纸、告白(bai)纸、💙家装(zhuang)壁(bi)纸、几(ji)大类(lei)包装(zhuang)设计纸)的共公武(wu)器装(zhuang)备(bei)。
的特色:
放(fang)卷:标准气压普升式(shi)放(fang)卷架(jia)、连体(ti)式(shi)放卷架(jia)等
收卷:持续性(xing)式气涨(zhang)轴、线(xian)上规范主(zhu)動充汽(qi)与翻看(可姿意(yi)护理收秘(mi)药外径)
围堵:♏得(de)到无(wu)杆汽缸(ga🎀ng)往(wang)回式主(zhu)动权切断长(zhang)距离
主要:伺服电机(ji)建筑机(ji)电定长(zhang)上料功(gong)能,在(zai)高速(su)的作业(ye)中保管员高精密(mi)度(du)较
具有(you)🐬定长高精度大,收(shou)卷环境整洁(jie),操控清新淡雅,尺寸雅观,机都不改变(bian)等副作用,还也能和全(quan)主动(dong)性变(bian)短(duan)包☂装方式机模块化涉及出厂线。
use:
This machine is a special equipment for producing hard paper core, soft paper core, and other small webs (gift paper, advertising paper, wallpaper, vario🍸us wra💛pping paper).
Features:
Unwinding: air pressure lifting unwinding frame, on🎃e-piece unwinding ⛎frame, etc.
Winding: continuous air-up shaft, computer controlled 🎐automatic inflation and opening (can adjust the reel diameter arbitrarily)
Cut off: use rodless 𒐪cylinder reciprocating automatic partition
Main control: S🥂ervo motor fixed length feeding, high precision during high speed operation
It has the functions of high fixed length precision, neat winding, simple operation, beautiful app🌄earance and stable performance. It can also form a production line with automatic shrink packaging machine.
基本匠(jiang)人运(yun)作(zuo) Main Technical Parameters
门焊(han)机(ji) Model | CLFJ-A600 | CLFJ-A800 | CLFJ-A1000 | |
防水(shui)卷材尺寸(cun) MAX.Parent Web Width | 600mm | 800mm | 1000mm | |
放卷(juan)口(kou)径 Max.parent Web Diameter | Φ600mm | Φ600mm | Φ600mm | |
收卷内径 Max.Rewinding Diameter | Φ260mm | Φ260mm | Φ260mm | |
速度(du) Max.Machine Speed | 10-150m/min | 10-150m/min | 10-150m/min | |
定(ding)长(zhang)精确(que)度Fixed length accuracy | ±5mm | ±5mm | ±5mm | |
总电机(ji)功(gong)率 Total Power | 2KW | 2.3KW | 3KW | |
份量 Machine Weight | 1000kg | 1200kg | 1500kg | |
样(yang)式形态尺(chiꦕ)寸(cun)规(gui)格(ge) Overall Dimensions 人物电流值 Working Voltage | 1300×1380×1600mm 二(er)相220V50HZ | 1300×1600×1600mm 二相220V50HZ | 1300×1800×1600mm 二相220V50HZ | |
纸芯型号Paper core specification | 20mm, 25mmꦬ, 38⛎mm等(or according to your requirement) | |||
