首要手艺参数：Main Technical Parameters

机型 Model	CLFQ-W1300	CLFQ-W1600
质料宽度 MAX.Width of raw material	1300mm	1600mm
放卷直径 Max.parent Web Diameter	Φ1200mm	Φ1200mm
收卷直径 Max.Rewinding Diameter	Φ1000mm	Φ1000mm
机器速率 Max.Machine Speed	10-300m/min	10-300m/min
资料厚度 Thickness of raw material	0.008-0.2mm	0.008-0.2mm
总功率 Total Power	19KW	23KW
分量 Machine Weight	4300kg	4800kg
形状尺寸 Overall Dimensions	2700×2900×1800mm	3000×2900×1800mm
分切宽度 Min.Slitting Width	50mm

可确定代谢物明确提出 定做法宝。

Can be made according to the produc๊t requires spe꧑cial equipment.

副产物声明函混用面积机器合适于各样小型防水卷材防水的模切，如30g/m2-300g/m2头层皮纸、白彩色卡纸、淋膜纸、铝铂、PVCPVC、锡纸等防水卷材防水的模切、复卷等。机可及的特色1. 这手机悦纳自己异步伺服控制器机电设备工程(矢量素材机电设备工程)吃妻上瘾、主动性锥度拉伸应变，里面卷取体例。主机设备悦纳自己调频调压，始终变快中若衡运转。2. 主动性计米、报警功能效果。收卷得到A、B气胀轴页面布局，卸装调控方便。3. 放卷去接纳光电公司主动权纠偏改进体系建设，使不准则素材能普遍分切机。4. 圆刀纵切废边主动地排出组装。5. 液压式主动地上料机，配气胀轴。6.导轨式主動切料装配工。

product manual

Scope of application

This machine is 🎃suitable for the slitting of various super-large coils, such as slitting and rewinding of 30g/m2-300g/m2 kraft paper, white cardboard, coated paper, aluminum foil, PVC plastic, tin foil and other c🍌oils.

Performance and characteristics

1. The machine adopts asynchronous servo motor (vector motor) control, automatic taper tension and center wi🔥nding method. T🐼he main engine adopts frequency conversion speed regulation to maintain balanced operation during acceleration.

2. Automatic metering and alarm function. The winding adopts the A and B air expansion s🎶ha🌱ft structure, and the unloading operation is convenient.

3. Unwinding adopts photoelectric automatღic correction correction syst𝄹em to make irregular materials cut normally.

4. The circular knℱife cuts the waste side auꦅtomatic discharge device.

5. Hydraulic automatic feeding, with air expans🗹ion shaft.

6. Rail type automatic cutting device.
